What is the thickness of these blades?

No, the small diameter 4"-4.5"-5" Diamax Cyclone Blades are thinner than the larger diameter 6"-7"-10" 4"-5"=1.23mm 6" - 7" =1.6mm 10"=2mm

1 4

Diamax Cyclone Porcelain Tile Turbo Diamond Blade | 4"

Name: Diamax Cyclone Porcelain Tile Turbo Diamond Blade
Brand: Diamax
SKU: 6094-4 in
Price: 18.4 USD
Availability: InStock

$18⁴⁰ USD ~~$23⁰⁰~~

Shipping calculated at checkout.

Brand: Diamax | SKU: 6094-4 in | MPN:

Blade Sizes

4" 4-1/2" 5" 7" 10"

Product variants

Shipping & Delivery

$13.95 Flat Rate shipping for orders under $500 (Other options at checkout)
Same-day shipping cut-off time for ground orders for CD stock items is 3:00 PM ET
Same-day shipping cut-off time for expedited orders for CD stock items is 12:00 PM ET
Shipping time is calculated by business days. Weekends do not count.
For Freight Items See Policy Here

Diamax Cyclone Porcelain Tile Turbo Diamond Blade

Dimple Style rim allows you to keep cutting dry while staying cool!

Features

A dimple-style rim minimizes heat caused by friction
Cooler rim temperatures increase the life and speed of your cut
The new diamond bond makes this the best continuous rim ever
It fits most standard handheld grinders and tile saws
For fast and chip-free cutting of porcelain tile
Minimize glazing
These blades are designed for wet or dry cutting

Additional Information

Don't drop and jam in the cut
Don't leave it on the a grinder when not in use
Don't grind and twist in the cut or side stress
Inspect blades before each use for any damage
Always leave the guard on a grinder

Diamax Cyclone Diamond Blade Specifications
Model	TBP40	TBP45	TBP50	TBP70	TBP100
Blade Size	4"	4-1/2"	5"	7"	10"
Rim Height	10 mm	10 mm	10 mm	10 mm	10 mm
Arbor	5/8" - 7/8" - 20 mm	5/8" - 7/8" - 20 mm	5/8" - 7/8" - 20 mm	5/8" – DKO	1" - 7/8" - 5/8"
RPM	15,200	13,200	12,200	8,600	6,100
Kerf	0.047"	0.047"	0.047"	0.055"	0.063"

Material	Performance
Ceramic	Excellent
Porcelain	Excellent
Marble	Not Recommended
Granite	Good
Hard Granite	Good
Glass	Not Recommended

5 stars: 8 (67%)
4 stars: 1 (8%)
3 stars: 0 (0%)
2 stars: 1 (8%)
1 star: 2 (17%)

Gregory

Thank you for sending me my diamond blade

I do recommend!

The best blade for grinder, works great with any kind of tile, perfect for 45 degree cut!

Love the blade

Was looking for another blade that was back ordered and had this blade suggested to me. I bought one to try and was more than satisfied. Sales staff has great product knowledge. Very satisfied

No good

After using this late for one week in less than 25 cuts. The whole one side broke off. I have never had a blde do this. Extremely disappointing. Will be going to manufacture for a refund.

Good

has anyone tried out the 7 or 10 inch version in a wet saw yet? The 4.5" dry grinder is awesome.

Great grinder blade

As a professional tile installer I burn through a lot of tools and equipment. I am constantly testing new brands or products. In 20 years of tiling this is by far my favorite blade. This cuts like a hot knife through butter compared to anything else I have ever used. It says for straight cuts only but I mainly use it for the toilet flange circle and it works great.

good blade

I am so happy with this blade good price thanks a lot contractor direct

Very good grinder blade

Love this blade! Works great on my Makita grinder clean cut on porcelain.

Good blade, but doesn't last

I got this blade as a replacement for my other blade that lasted for a year. It worked well for the first while, but after about one month the blade started chipping off. The silver part of the outside edge broke off about a third of the blade. It's a good blade, but it doesn't last. I would recommend looking for a different option. --We appreciate your feedback! These rims are more fragile than a typical diamond blade and can become compromised if the rim is damaged at all from handling (i.e. thrown in a van, dropped on the ground). - CD

My only blade

I use this on my grinder for all my cuts. Not many blades come I 6" I am so glad I found this blade and found it in the size I like. Awesome

A+ Blade!

Let me start by saying I used this blade in the past and then my supplier stopped carrying them, so I am beyond thrilled that Contractors Direct started carrying them. The Diamax Cyclone blade is one of the best grinder blades I have ever used!

Recommend this blade to all my colleagues

I was looking for a thicker 10" blade because the last one I used would flex when I tried to make cuts too close to the edge (trying to trim a 1/16th off). This blade was a huge upgrade! It also cuts very clean. I recommend it. Nice price point and well worth the money.

Do you have a version of this blade that would fit on a skill saw?

Contractors D.

This blade is not designed for use on a Skilsaw. It is designed to fit on angle grinders and tile saws. Using this blade on a Skilsaw could be dangerous and it NOT advised.

Does this come in a 4 1/2" type 27 wheel?

Contractors D.

Unfortunately this blade does not come in a type 27 wheel.
